| Camera |
| Image Sensor |
1/2.8" CMOS |
| Core Processor |
ARM9 Architecture |
| Operating System |
Embedded Linux |
| Signal System |
PAL/NTSC |
| Min. Illumination |
Color: 0.002Lux(F1.2,AGC ON) |
| B/W: 0.001Lux(F1.2,AGC ON); 0 Lux with IR |
| Shutter Time |
1s to 1/100,000s |
| Lens |
Motorized 2.8-12mm, Angle of View: 92°?38.6° |
| Lens Mount |
φ14 |
| Auto Iris |
DC Drive |
| Day& Night |
IR Cut Filter with Auto Switch |
| Wide Dynamic Range |
140 dB |
| Digital Noise Reduction |
3D DNR |
| Focus |
Auto |
| Compression Standard |
| Video Compression |
H.265/H.264 HP/MP/BP/M-JPEG |
| Video Bit Rate |
32Kbps~16Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM/AAC |
| Audio Bit Rate |
G711 8KHz, 64kbps
ADPCM 8KHz, 32kbps
AAC 48KHz, 96-320kbps |
| Image |
| Max. Image Resolution |
1920x1080 |
| Frame Rate |
50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps(1280×720), Up to 1280*720@50fps |
| 60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps(1280×720), Up to 1280*720@60fps |
| Triple Stream |
Mainstream: 1080P(1920*1080) |
| Substream: D1(704*576) |
| 3rd stream: 720P(1280*720) |
| Image Settings |
Brightness, Saturation, Contrast,Flip Mode Adjustable by Client Software or Web Browser |
| HLC |
Y |
| Smart Defog |
Y |
| Corridor Format |
Y, Available for 720P and Above |
| EIS |
Y |
| ROI |
4 Zones |
| Privacy Mask |
4 Zones |
| Picture Overlay |
200 × 200, BMP 24bit, Zone Configurable |
| OSD |
16×16, 32×32, 24×24, 48×48, 64×64, 96×96 Size Letters Such as Week, Date, Time, Total 5 Regions |
| Network |
| Browser |
IE8,IE9,IE10,IE11,Firefox24 |
| Network Storage |
FTP |
| NTP |
Y |
| ANR |
Y, Auto store video in SD card when NVR disconnected, and upload video to NVR when resumed connection(Only Support Tiandy ANR NVR) |
| Видеоаналитика |
Tripwire / Double Tripwire / Периметр / Отказ от объекта / Объект потерян / работает / слоняется без дела / парковка / толпа / аудио ненормальное обнаружение / видео ненормальное обнаружение |
| Alarm Trigger |
Motion Detection/IP Conflict/MAC Conflict/Port Alarm/Mask Alarm |
| Protocols |
IPv4/IPv6/HTTP/802.1x/FTP/SMTP/UPnP/SNMP/DNS/DDNS/NTP/RTSP/TCP/UDP/DHCP/PPPoE |
| User Permission |
4 Level/8 Users |
| Remote Connection |
5 Users Access at the Same Time |
| System Compatibility |
ONVIF (Profile S), SDK |
| Interface |
| Audio Input |
1-ch |
| Audio Output |
1-ch |
| Communication Interface |
1-ch RJ45 10M / 100M Ethernet Interface |
| Alarm Input |
2-ch |
| Alarm Output |
1-ch |
| Video Output |
1Vp-p Composite Output(75Ω/BNC, for Internal Setup) |
| On-board Storage |
MicroSD Card Slot, up to 128 GB |
| Reset Button |
Y |
| Extension |
USB |
| General |
| Language |
English,Spanish,Korean,Italian,Turkish,Thai,Russian,Traditional Chinese,Simplified Chinese,Polish,French |
| Operating Conditions |
-35??60?(IR OFF) /-35??40?(IR ON), 0?95% RHG |
| Power Supply |
DC12 V ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5W(IR OFF) (ICR Instant Switch 12W) |
| Max. 7.5W(IR ON) |
| Circuit Protection |
TVS 6000V, Lightning/Surge Protection: (Power 2000V, RJ45 1000V) |
| Impact Protection |
IP67 |
| IR Range |
50m |
| IR LEDs |
54pcs φ5 Array IR LEDs |
| Dimensions |
337mm×107mm×107mm |
| Weight |
1.3KG (IP Camera Only); 1.6KG (with Packing Box) |
